Description
The TOTO WASHLET+ EP Wall-Hung Elongated Toilet combined with the WASHLET S5 Bidet Seat offers a premium bathroom solution in a sleek matte silver finish. Featuring the DuoFit In-Wall Dual-Flush Tank System with 0.9 and 1.28 GPF options, it ensures efficient water use without compromising performance. The advanced WASHLET S5 seat provides customizable cleansing functions for superior hygiene and comfort. Engineered for seamless integration and modern aesthetics, this combination is ideal for those seeking expert-level technology and design in their bathroom fixtures.
California residents see Prop 65 WARNINGS
Components
CWT4283446CMFGA#MS EP WASHLET+ with S5
- CT428CFGT40#01 EP Wall-Hung Toilet
- WT173M In-Wall Tank System (Copper Pipe)
- SW3446#01 S5 WASHLET+ Elongated WASHLET
- THU805 WASHLET connection kit
- YT930#MS Matte Silver Basic Round Push Plate
SKU
CWT4283446CMFG#MS
Features
- Ultra high-efficiency DYNAMAX TORNADO FLUSH® system -1.28 GPF / 0.9 GPF (4.8 LPF / 3.4 LPF)
- CEFIONTECT® ceramic glaze minimizes waste from sticking to porous ceramic surfaces
- Universal Height
- Elongated shape front bowl
- Elongated front WASHLET toilet with WASHLET+ S5 set
- Adjustable 15”-19” mounting height
- Saves up to 9” of floor space compared to standard floor-mounted toilet
- Supports up to 880lbs
- Commercial 2” x 6” or optional residential installation with 2” x 4” wall studs with waste outlet kit
- Copper supply line
- Matte Silver Basic Round Push Plate
Specifications
| CT428CFGT40 | S5 | WT173M | |
| Water Use | 1.28 / 0.9 GPF (4.8 / 3.4 LPF) | NA | 1.28 GPF / 0.9 GPF (4.8 LPF / 3.4 LPF) |
| Flush System | DYNAMAX TORNADO FLUSH® | NA | Dual flushing |
| Min. Water Pressure | 8 psi (static) | NA | 8 psi (static) |
| Water Surface | 5-1/2” X 4-1/8” | NA | NA |
| Trap Diameter | 2-1/8” | NA | NA |
| Installation Height | 15” to 19” | NA | 15” to 19” |
| Trap Seal | 2-1/8” | NA | NA |
| Warranty | One Year Limited Warranty | One Year Limited Warranty | One Year Limited Warranty |
| Material | Vitreous China | NA | Various |
| Shipping Weight | 68 lbs | 15.4 lbs | 44 lbs |
| Shipping Dimensions | 22” L x 14.6” W x 16.5 H | 24-3/8"L x 17-9/16"W x 7-7/16"H | 47” L x 26-1/2” W x 5-3/4” H |
Product Specifications
Spec Sheet - CWT4283446CMFG#MS
Installation and Owner's Manual
